What would cause zits on curved walls only?

A forum dedicated to the stock LulzBot TAZ 3D Printer
billyd
Posts: 234
Joined: Thu Mar 12, 2015 11:06 pm

What would cause zits on curved walls only?

Post by billyd » Tue Feb 23, 2016 12:29 pm

I have a Taz 5 and S3D. I am not sure if this issue is slicer related or hardware related.

I get perfectly clean straight walls on my prints, but curved walls have blemishes on them (from starting and stopping layers). I have cured these on straight walls using coasting and negative restart after retractions and they are perfection But on curved walls the blemishes remain.

Is this some sort of issue with the hardware trying to drive 3 steppers at one time? X Y and the extruder?

Sebastian
Posts: 514
Joined: Sun Sep 13, 2015 5:54 am

Re: What would cause zits on curved walls only?

Post by Sebastian » Tue Feb 23, 2016 12:45 pm

Do you have a picture?

User avatar
piercet
Posts: 4027
Joined: Sun Aug 25, 2013 1:37 am
Location: Battleground, WA
Contact:

Re: What would cause zits on curved walls only?

Post by piercet » Tue Feb 23, 2016 1:18 pm

I get some of exactly what you are describing with Slic3r as well. I don't think it's a software issue, and I don't think it is a motion segment issue. I think it has to do with the extruder itself actually, and maybe the controller. On a straight run any pressure variances tend to not show up because outflow is constant. As soon as it hits a curve and that direction change though, it seems like any excess pressure from that layer, especially on a really well dialed in machine that shows no other blemishes, is going to come out at that location. Possibly a pressure wave, possibly a belt handoff issue, maybe a nozzle wobble, but that shouldn't be an issue on my machine at all at this point. I'm not really sure yet. Slowing the speed does seem to diminish the effect. I'm not convinced it isn't some sort of minor overextrusion. I really need to get a high speed camera now to figure out exactly what is going on there for sure though. It doesn't seem to be taz specific either. You can see similar artifacts on really well dialed in ultimaker and mendelmax prints in similar locations. It definitly varies with layer height as well. It's every other layer, or every two layers or so, but intermittantly too, which would make me think it's extrusion related.

My next testing phases are as follows:
1. Finish the sensor project (or at least the width sensor) and see if its due to variances in filliament width
2. Finish the belted bondtech standard filliament extruder to see if this is a filliament feed issue
3. If that doesn't fix the issue, build a pen plotter insert with 3 pens in a triangle shape around the center of where the nozzle would be and an automatically raising writing surgface of some sort to see if the motion path through corners is accurate and precise on each pass
4. Get a high speed camera to see what the hell is actually going on (the cheapest possible option of which seems to be about $170...)

billyd
Posts: 234
Joined: Thu Mar 12, 2015 11:06 pm

Re: What would cause zits on curved walls only?

Post by billyd » Tue Feb 23, 2016 1:19 pm

I'll post pics tonight. But trust me the straight vertical walls are perfect in every direction, and every curved wall is covered with blemishes.

billyd
Posts: 234
Joined: Thu Mar 12, 2015 11:06 pm

Re: What would cause zits on curved walls only?

Post by billyd » Tue Feb 23, 2016 1:22 pm

piercet wrote:I get some of exactly what you are describing with Slic3r as well. I don't think it's a software issue, and I don't think it is a motion segment issue. I think it has to do with the extruder itself actually, and maybe the controller. On a straight run any pressure variances tend to not show up because outflow is constant. As soon as it hits a curve and that direction change though, it seems like any excess pressure from that layer, especially on a really well dialed in machine that shows no other blemishes, is going to come out at that location. Possibly a pressure wave, possibly a belt handoff issue, maybe a nozzle wobble, but that shouldn't be an issue on my machine at all at this point. I'm not really sure yet. Slowing the speed does seem to diminish the effect. I'm not convinced it isn't some sort of minor overextrusion. I really need to get a high speed camera now to figure out exactly what is going on there for sure though. It doesn't seem to be taz specific either. You can see similar artifacts on really well dialed in ultimaker and mendelmax prints in similar locations. It definitly varies with layer height as well. It's every other layer, or every two layers or so, but intermittantly too, which would make me think it's extrusion related.

My next testing phases are as follows:
1. Finish the sensor project (or at least the width sensor) and see if its due to variances in filliament width
2. Finish the belted bondtech standard filliament extruder to see if this is a filliament feed issue
3. If that doesn't fix the issue, build a pen plotter insert with 3 pens in a triangle shape around the center of where the nozzle would be and an automatically raising writing surgface of some sort to see if the motion path through corners is accurate and precise on each pass
4. Get a high speed camera to see what the hell is actually going on (the cheapest possible option of which seems to be about $170...)

I think (my guess) it is related to the printer pcb. I think that it has trouble keeping three hard working steppers in perfect sync and it effects extruder function negatively (in the most obvious manner, during retracts and restarts). This behavior happens to all Taz-like printers that use the same controller as far as I know.

billyd
Posts: 234
Joined: Thu Mar 12, 2015 11:06 pm

Re: What would cause zits on curved walls only?

Post by billyd » Tue Feb 23, 2016 1:25 pm

piercet wrote:I get some of exactly what you are describing with Slic3r as well. I don't think it's a software issue, and I don't think it is a motion segment issue. I think it has to do with the extruder itself actually, and maybe the controller. On a straight run any pressure variances tend to not show up because outflow is constant. As soon as it hits a curve and that direction change though, it seems like any excess pressure from that layer, especially on a really well dialed in machine that shows no other blemishes, is going to come out at that location. Possibly a pressure wave, possibly a belt handoff issue, maybe a nozzle wobble, but that shouldn't be an issue on my machine at all at this point. I'm not really sure yet. Slowing the speed does seem to diminish the effect. I'm not convinced it isn't some sort of minor overextrusion. I really need to get a high speed camera now to figure out exactly what is going on there for sure though. It doesn't seem to be taz specific either. You can see similar artifacts on really well dialed in ultimaker and mendelmax prints in similar locations. It definitly varies with layer height as well. It's every other layer, or every two layers or so, but intermittantly too, which would make me think it's extrusion related.

My next testing phases are as follows:
1. Finish the sensor project (or at least the width sensor) and see if its due to variances in filliament width
2. Finish the belted bondtech standard filliament extruder to see if this is a filliament feed issue
3. If that doesn't fix the issue, build a pen plotter insert with 3 pens in a triangle shape around the center of where the nozzle would be and an automatically raising writing surgface of some sort to see if the motion path through corners is accurate and precise on each pass
4. Get a high speed camera to see what the hell is actually going on (the cheapest possible option of which seems to be about $170...)

It can't be 1, because that would effect all walls the same wouldn't it? The effect would be random in appearance.
2 seems unlikely because the feed shouldn't really be effected by the other axes' motion

I think it's data choke of some kind.

User avatar
piercet
Posts: 4027
Joined: Sun Aug 25, 2013 1:37 am
Location: Battleground, WA
Contact:

Re: What would cause zits on curved walls only?

Post by piercet » Tue Feb 23, 2016 1:42 pm

It's unlikely that filliament width or feed is the issue, but it might be. On long sections any variance might just be small enough that it gets buried in the part or the extrusion wall. It may only be showing up because of the effective compression of the corners. It's the whole oval racetrack effect. The car wheels on the inside travel less than the wheels on the outside, because the inner track is shorter. Same thing with filliament extrusion in corners. but software seems to be handling it properly in most layers, but not all of them. or software is handling it just fine and it's something else entirely.

discojon
Posts: 432
Joined: Sat Mar 07, 2015 1:54 pm

Re: What would cause zits on curved walls only?

Post by discojon » Wed Feb 24, 2016 1:25 pm

I get the same thing using S3D. I attribute it to Marlin / slicers not using native arcs when slicing the models. I'd be interested to see the results from someone using native arcs (G02 / G03) insteard of G1 segments.
TAZ 5, Open rails X,Y,Z. Marlin 1.1 RC2. Mangrove dual fan, reinforced extruder mount

kcchen_00
Posts: 1721
Joined: Thu Feb 19, 2015 12:42 am

Re: What would cause zits on curved walls only?

Post by kcchen_00 » Wed Feb 24, 2016 10:09 pm

Overhang or curved exteriors? Overhangs hard to cure, but curved exteriors can be mitigated. I still get zits in random and usually in groups.

I had a challenging custom 1911 grip that helped me understand how different settings affect the final finish. Here's a few that I feel that made a difference:
- Slow the print down - usually print at 90mm/s (5400mm/min), I'll drop to 70mm/s (4200mm/min)... with a target perimeter underspeed of 40mm/s (2400mm/min). Drop the infill speed a bit also...
- Check your extrusion rate... I find 90-95% flow multiplier helps with print accuracy and top layer. It may also help with the exterior zits, but I haven't compared in a while.
- Try rotating the object on the bed. A 45deg rotation in the Z-axis can help.
- In S3D, try the different options for the "Layer" -> "Start Points"... for a while I chose a start point to put it on a seam or corner if possible.


I ended up printing the 1911 grip upright and side-by-side (flat sides facing each other). The knife edge of the grip posed a problem, which I added a raft with "tack" points to minimize the bottom edge from warping / curving. The client was pretty happy with the time and effort... I probably went through a spool of black ABS trying to perfect the print.

Hope some of the tips help.

billyd
Posts: 234
Joined: Thu Mar 12, 2015 11:06 pm

Re: What would cause zits on curved walls only?

Post by billyd » Thu Feb 25, 2016 9:29 am

discojon wrote:I get the same thing using S3D. I attribute it to Marlin / slicers not using native arcs when slicing the models. I'd be interested to see the results from someone using native arcs (G02 / G03) insteard of G1 segments.
Well I don't think that's even possible for a slicer to use true curves since they use STL files which are all straight line polys. You'd have to develop a slicer that used a true solid model and boy my brain hurts thinking about the complexity of trying to do that. It could be done obviously but by somebody a lot smarter than most.
